Highlights
- Enterprise Grade Smart Tracking Dual Lens PTZ Camera
- Dynamic auto framing: secondary AI lens detects all participants, new participants trigger PTZ lens to dynamically frame all participants
- Simultaneous 3-way output: USB, HDMI and IP connections
- 85° field of view
- Smart Framing with People Counting API
- Certified for use with Zoom
Resources
AVer CAM550 Dual Lens Smart Tracking Camera with AI Technology
Turn all your meetings into "smart" meetings.
The CAM550, 4K UltraHD dual lens camera equipped with an AI lens, delivers Smart Framing features along with a full view of meeting attendees (even detecting people entering the room). The Smart Gallery feature puts up clear views of every participant during video calling, even in a large conference rooms. Go touchless with gesture controls operation to enjoy a fluent, safe video calling experience. UltraHD dual-lens camera technology captures the room in its entirety, providing a professional video conferencing experience for a wide range of rooms sizes, from medium to large and even classrooms.
4K dual lens camera
Capture a complete view of the room with wide-angle clarity. The CAM550 is equipped with two 4K lenses. The first is a PTZ camera with 12X optical zoom (24X total zoom) to clearly frame meeting participants in medium and large rooms. The second is an AI lens with 95° FOV to provide a panoramic view of the room. Picture-in-picture functions to simultaneously view the speaker and a panoramic view of the room.
Enhance meetings with dynamic framing
Enhance meeting efficiency with dynamic Framing. When newcomers walk in, the secondary AI lens springs to action to detect them, then the PTZ camera automatically re-frames participants for perfect video calling. Through fully automatic operation, this dynamic framing optimizes meetings and protects the safety of participants.
HDMI enables dual display and 3-way output
The CAM550 features an HDMI connection so you can enable a second display for virtual meetings. Simultaneously connect HDMI, USB, and IP streaming broadcasting. Simultaneous connections allow you to easily monitor your stream during recording using a local recording service to watch recordings later.
Control Camera with Gestures
Camera can easily be controlled and enable AI functions by holding up one finger on either side of your face. Take advantage of built-in AI gesture recognition to operate the camera and eliminates touchpoints to increases meeting safety. Gesture controls can be easily switched on and off (requires the PTZApp 2).
Improved Dynamic Framing Technology
Enhance meeting efficiency with dynamic Framing. When newcomers walk in, the secondary AI lens springs to action to detect them, then the PTZ camera automatically re-frames participants for perfect video calling. Through fully automatic operation, this dynamic framing optimizes meetings and protects the safety of participants.
IP based management and streaming
Ethernet network connectivity to manage and control the CAM550 Smart Tracking Dual Lens Camera via a web browser or centralized management software. Easily connect live video content from the CAM550 Smart Tracking Dual Lens Camera using an H.264 RTSP/RTMP stream to your cloud base or on premise streaming delivery network.
AVer CAM550 Smart Tracking Dual Lens Camera Specifications
Primary PTZ Camera
- Zoom: 24X Zoom*: 12X optical; 2X digital zoom
- Wide field of view (DFOV): : DFOV 85°; HFOV 76°; VFOV 46°
- Image sensor: Sony 4K EXMOR, crystal clear in any lighting
- Frame rates: (16:9) 4K 30fps; 1920 x 1080, 1600 x 900, 1280 x 720, 960 x 540, 848 x 480, 800 x 448, 640 x 360, at 60, 30, 15fps; (4:3) 1280 x 960, 800 x 600, 640 x 480 at 60, 30, 15fps
- SmartFrame for automatic FOV adjustment to fit all participants
- True WDR up to 120db: Superb backlight compensation technology for optimizing light balance in high-contrast conditions
- AE, white balance: auto, manual override by PTZApp
- Minimum focus distance: 1.5m
Secondary Fixed Camera
- Frame rates and resolution set according to PTZ lens settings
- Image sensor: Sony 4K EXMOR
- Wide field of view: DFOV 95°; HFOV 78°; VFOV 50°
Connectivity
- USB type-B 3.1 connector, backward compatible with USB 2.0
- 12V/2A DC jack power adapter
- Mini DIN9 for RS232 in & out connection (VISCA control panel and camera daisy-chain)
- IP (RJ45)
- HDMI
In the Box
- CAM550 Camera unit
- Remote control
- USB 3.1 Type-B to Type-A cable (10ft/3m)
- HDMI cable (10ft/3m)
- Wall-mount bracket
- Mini DIN9 to mini DIN8 RS232 adapter
- Power adapter (10ft/3m)
- Quick-start guide
Warranty
- 3-year limited hardware warranty on main unit (Battery, remote and accessories limited 1-year warranty)
Warranty Information
3-year limited hardware warranty on main unit (Battery, remote and accessories limited 1-year warranty)Product Videos
