Highlights
- Wireless presentation with 4K content sharing using two next-gen ClickShare Buttons (5th Generation) with USB-C DisplayPort.
- Wireless BYOD support for Microsoft Teams Rooms to run other conferencing platforms, including Zoom, Webex, and Google Meet.
- Built on the Microsoft Device Ecosystem Platform (MDEP) and requires a Microsoft Teams Rooms license.
- Dual display support, with HDMI-1 driving up to UW5K WUHD (5120 x 2160) and HDMI-2 up to 4K UHD (3840 x 2160), both at 30Hz.
- Huddly C1 video bar with a 150° lens camera, 16 smart microphones, and hi-fi stereo speakers, scaling from standalone to multi-camera.
- Wireless reach of up to 30 m (100 ft.) between the ClickShare Button and the Base Unit.
- Cloud device monitoring and reporting through XMS Cloud.
Ideal For
- Small-to-medium Microsoft Teams Rooms deployments
- BYOD and BYOM rooms needing wireless content sharing alongside a managed room camera
- Multi-platform rooms running native Teams with wireless BYOD support for Zoom, Webex, or Google Meet
- Multi-room or multi-site standardization on a certified Teams Rooms bundle
- IT-managed environments using XMS Cloud for fleet monitoring
Resources
Barco ClickShare Hub Pro + Huddly® C1™ Microsoft Teams Rooms Bundle
The ClickShare Hub Pro + Huddly C1 bundle pairs Barco's ClickShare Hub Pro wireless presentation and conferencing base with the Huddly C1 AI-driven video bar to deliver a Microsoft Teams Rooms solution built for small-to-medium meeting rooms. ClickShare Hub Pro handles one-click meeting start from the Control Panel and 4K wireless content sharing through two next-gen ClickShare Buttons, while the Huddly C1 provides camera, microphone, and speaker coverage for the room.
The system runs on the Microsoft Device Ecosystem Platform (MDEP) and requires a Microsoft Teams Rooms license, which should be confirmed and provisioned separately from the hardware purchase. Dual-display output is supported, with each HDMI port carrying a different maximum resolution, so display assignment should be planned before installation. The Huddly C1 can also scale into a multi-camera Crew configuration if room requirements grow.
Key Specifications
- Operating system: Android (MDEP)
- Microsoft Teams Rooms license: required
- Video outputs: HDMI-1 up to UW5K WUHD (5120 x 2160) @30Hz; HDMI-2 up to 4K UHD (3840 x 2160) @30Hz; eDP (Control Panel) HD (1280 x 800) @60Hz
- Video input: 4K UHD (3840 x 2160) @30Hz via HDMI 2.0
- Camera: Huddly C1 video bar, 150° lens
- Microphones: 16 smart microphones
- Speakers: hi-fi stereo
- ClickShare Buttons: 2x 5th Generation, USB-C DisplayPort
- Wireless: IEEE 802.11 a/b/g/n/ac/ax/be and Bluetooth 5.3; 2.4GHz, 5GHz, and 6GHz bands
- Wireless reach: up to 30 m (100 ft.) between Button and Base Unit
- Base Unit connections (rear): 1x Ethernet LAN 1Gbit, 1x USB-C Power Delivery 3.1 EPR, 2x HDMI 2.0 output, 2x USB-C 2.0/3.0, 1x USB-A 2.0/3.0, 1x USB-C 2.0/3.0 device + DisplayPort output, 1x USB-C 2.0 + DisplayPort output; front: 1x USB-C 2.0/3.0
- Power consumption: 160 W operational (max)
- Power supply: external USB-C charger, 100 W (PD3.0 SPR) or 180 W (PD3.1 EPR)
- Base Unit dimensions (H x W x D): 37 x 180 x 180 mm
- Base Unit weight: 720 g
- Control Panel: 10.1-inch projected capacitive touchscreen, 1280 x 800 @60Hz, 300 nits, 1000:1 contrast, up to 4 touch points
- Certifications: FCC/CE
- Anti-theft: Kensington lock on Base Unit and Control Panel
What's Included
- ClickShare Hub Pro Base Unit
- ClickShare Control Panel (10.1-inch touchscreen)
- 2x ClickShare Buttons, 5th Generation
- Huddly C1 video bar
- ClickShare 10M 20W USB-C AOC cable (directional)
- External USB-C power adapter and regional power cord
Certifications and Compatibility
- Certified for Microsoft Teams as a bundle; requires a Microsoft Teams Rooms license.
- Supports wireless BYOD for other videoconferencing platforms, including Zoom, Webex, and Google Meet.
- ClickShare App system requirements, minimum: Intel Core i3 or AMD Ryzen 5, 8GB RAM, Windows 10 20H2; Intel Core i3 or Apple Silicon M1, 8GB RAM, macOS 11 Big Sur.
- ClickShare App system requirements, recommended: Intel Core i5/Ultra 5 or AMD Ryzen 7, 8GB RAM, Windows 11; Apple Silicon M3, 8GB RAM, latest macOS.
- Huddly C1 scales into a multi-camera Crew configuration for rooms with growing camera needs.
Design Considerations
- Confirm and provision the Microsoft Teams Rooms license separately before deployment; it is not included with the hardware.
- Plan display assignment before installation. HDMI-1 and HDMI-2 support different maximum resolutions, so match each display to the correct port.
- Confirm the power adapter and cable used, since maximum Power Delivery differs between the 100 W (PD3.0 SPR) and 180 W (PD3.1 EPR) options.
- Consider the Huddly C1's multi-camera Crew scaling path if the room may need additional camera coverage later.
Licensing, Warranty & Support
A Microsoft Teams Rooms license is required and is provisioned separately from the hardware purchase. Barco's standard warranty on this bundle is 3 years. The system is managed and monitored through XMS Cloud.
VideoConferenceGear.com Assistance
We can help confirm Teams Rooms licensing requirements before you order, plan display assignment across the HDMI-1 and HDMI-2 outputs, and advise on power adapter selection for your room. We can also help you evaluate whether the Huddly C1's Crew scaling path fits a future multi-camera upgrade, and support standardizing this bundle across a multi-room or multi-site rollout.
Common Questions
Does this bundle require a Microsoft Teams Rooms license?
Yes. The system is built on the Microsoft Device Ecosystem Platform and requires a Microsoft Teams Rooms license, which is provisioned separately from the hardware.
Can it be used with platforms other than Microsoft Teams?
Yes. It supports wireless BYOD for other videoconferencing platforms, including Zoom, Webex, and Google Meet.
What is the wireless range of the ClickShare Button?
Up to 30 m (100 ft.) between the ClickShare Button and the Base Unit.
What warranty applies to this bundle?
3 years.
Can the Huddly C1 scale to additional cameras later?
Yes. The Huddly C1 is modular and can scale from a standalone video bar into a multi-camera Crew configuration.
