Highlights
- Purpose-built mini-PC that supplies the Windows compute for a Yealink Microsoft Teams Rooms system.
- Intel Core Ultra 5 125H processor with integrated NPU for AI-driven Teams Rooms features, including Copilot on Teams Rooms on Windows.
- 16 GB DDR5 memory and 256 GB SSD, running Windows 11 IoT Enterprise with the license preloaded.
- Drives up to three displays via 3 HDMI outputs, plus a 4K HDMI input for wired content sharing.
- Wired or wireless connection to Yealink touch consoles, with Wi-Fi 6 and Bluetooth 5.2.
- Enterprise security with TPM 2.0, UEFI Secure Boot, and AV-LAN and internet network separation.
- Cable-locking and flexible wall, under-table, or behind-display mounting for secure, tool-free service.
Ideal For
- Yealink Microsoft Teams Rooms builds needing the dedicated room compute unit
- Room refresh projects replacing aging room PCs with an AI-capable platform
- Rooms standardizing on Yealink touch consoles (CTP25 or MTouch Plus)
- Deployments requiring AV-LAN and corporate-network separation for security
- Multi-room standardization on a consistent Teams Rooms compute platform
Yealink MCore 4 Mini-PC for Microsoft Teams Rooms, Intel Core Ultra 5 AI Processor (MCORE4-MS, 1306064)
The MCore 4 (MCORE4-MS) is the dedicated mini-PC that runs Microsoft Teams Rooms on Windows for a Yealink room system. It is built on an Intel Core Ultra 5 125H processor with an integrated NPU, paired with 16 GB of DDR5 memory and a 256 GB SSD, and it ships with Windows 11 IoT Enterprise and the Teams Rooms app preloaded. As an always-on room computer, it removes the need for anyone to bring a laptop to drive the room.
The MCore 4 is the compute component of a room system, so it is specified alongside a camera, room audio, and a touch console rather than on its own. It connects to a Yealink touch console (CTP25 or MTouch Plus) over IP or wired connection, drives up to three displays from its three HDMI outputs, and accepts wired content on its 4K HDMI input. Before ordering, confirm the room's touch console and peripherals, since this SKU is compute-only, plan display count against the three HDMI outputs, and confirm a Microsoft Teams Rooms license and wired network are in place. This is the Teams SKU (1306064); the Zoom variant is a separate part number.
Key Specifications
- Manufacturer model: MCORE4-MS (SKU 1306064), Microsoft Teams variant
- Product type: Mini-PC compute unit for Microsoft Teams Rooms on Windows
- Processor: Intel Core Ultra 5 125H with integrated NPU
- Memory: 16 GB DDR5
- Storage: 256 GB SSD
- Operating system: Windows 11 IoT Enterprise, license preloaded, with Microsoft Teams Rooms app
- Video output: 3 HDMI out (1x HDMI 2.1, 2x HDMI 2.0), up to three displays, up to 3840 x 2160
- Video input: 1x HDMI in (4K), with EDID and CEC support
- USB: 4x USB-A 3.0
- Touch console: 1x RJ45 MTouch port
- Network: 1x Gigabit Ethernet RJ45, plus AV-LAN and internet separation support
- Wireless: Wi-Fi 6 (802.11ax), Bluetooth 5.2
- Audio: 1x 3.5 mm
- Security: TPM 2.0, UEFI Secure Boot, Kernel DMA Protection, security lock slot
- Management: Windows Autopilot supported
- Environmental: operating temperature 0 to 40°C, humidity 10 to 95%
- Mounting: wall mount, under-table, or behind-display, with cable-locking mechanism
What's Included
- MCore 4 mini-PC
- Wall-mount bracket
- Power adapter
- HDMI 2.1 cable (1.8 m)
- HDMI 2.0 cables, 2x (1.8 m)
- Preloaded Windows 11 IoT Enterprise OS and license, Microsoft Teams Rooms app, and Yealink camera control plugin
- Documentation
Certifications and Compatibility
- Microsoft Teams Rooms on Windows: certified. Ships with Windows 11 IoT Enterprise and the Teams Rooms app, and supports Microsoft Copilot on Teams Rooms on Windows.
- Touch consoles: connects to the Yealink CTP25 or MTouch Plus. This SKU does not include a touch console.
- Displays: up to three displays from the three HDMI outputs, with a separate 4K HDMI input for content.
- Cameras and audio: pairs with Yealink room cameras and audio to form a complete room system, specified separately.
- Networking: supports AV-LAN and internet separation to isolate AV devices from the corporate network.
- Platform variants: the same MCore 4 hardware is offered in a separate SKU for Zoom Rooms (1306067) and is used with RingCentral Rooms. This SKU (1306064) is the Microsoft Teams variant.
- Management: supports Windows Autopilot for zero-touch provisioning.
Design Considerations
- Specify the touch console and peripherals separately. This SKU is the compute unit only and does not include a CTP25 or MTouch Plus, camera, or audio.
- Plan display count against the three HDMI outputs, and reserve the HDMI input for wired content sharing.
- Provide a Microsoft Teams Rooms license and a wired network. The license is not included with the hardware.
- Use AV-LAN and internet separation where security policy requires isolating AV devices from the corporate network.
- Choose the mounting location (wall, under-table, or behind-display) during design, and use the cable-locking mechanism for secure, tool-free service access.
- Confirm this is the Teams variant if the room runs Teams. Zoom rooms use the separate Zoom SKU.
Licensing, Warranty & Support
The MCore 4 ships with Windows 11 IoT Enterprise and its license preloaded, along with the Microsoft Teams Rooms app and the Yealink camera control plugin. A Microsoft Teams Rooms license is required for room operation and is separate from the hardware, applying under your organization's Microsoft agreement. The MCore 4 is covered by Yealink's standard limited hardware warranty, with terms available from Yealink or an authorized reseller at the time of purchase. Configuration and remote management are supported through Windows Autopilot, Yealink's management platforms, and the Microsoft Teams Admin Center for the room account.
VideoConferenceGear.com Assistance
We can confirm the MCore 4 is the right compute unit for your Yealink Teams Rooms build, and help specify the touch console, camera, and audio that complete the room, since this SKU is compute-only. We can plan display count and HDMI routing against the three outputs and the content input, advise on AV-LAN and internet separation for security, and confirm the Teams Rooms licensing and network prerequisites. For multi-room and multi-site programs we can help standardize the compute platform and provisioning so every Teams room is deployed the same way.
Common Questions
Does this include a touch console?
No. The MCORE4-MS is the compute unit only. A Yealink touch console, either the CTP25 or the MTouch Plus, is ordered separately.
Is it certified for Microsoft Teams?
Yes. It is a Microsoft Teams certified mini-PC running Windows 11 IoT Enterprise with the Teams Rooms app, and it supports Microsoft Copilot on Teams Rooms on Windows.
How many displays can it drive?
Up to three, from its three HDMI outputs. A separate 4K HDMI input is provided for wired content sharing.
What processor and memory does it have?
An Intel Core Ultra 5 125H with an integrated NPU, 16 GB of DDR5 memory, and a 256 GB SSD.
Is this the Teams or the Zoom version?
This SKU (1306064) is the Microsoft Teams variant. The Zoom Rooms version is a separate part number.
Is a Teams Rooms license included?
No. The Windows 11 IoT Enterprise license is preloaded, but a Microsoft Teams Rooms license is separate and applies under your Microsoft agreement.
