Highlights
- Complete multi-camera Native Microsoft Teams Rooms on Windows system for extra-large rooms and ProAV spaces.
- Two UVC86 4K Ultra HD PTZ cameras with 12x optical zoom, Speaker Tracking, and Presenter Tracking.
- AVHub multi-camera processor supports up to 9 simultaneous cameras, with Multi-Camera IntelliFocus for dynamic framing.
- MCore 4 mini-PC (Intel Ultra5 125H, 16 GB DDR5, 256 GB SSD) preloaded with Windows 11 IoT Enterprise and the Teams Rooms app.
- MTouch Plus 11.6-inch touch console for one-touch meeting management.
- RoomSensor automatically wakes the system on occupancy via Bluetooth.
- MVC-BYOD-Extender provides USB connectivity for non-Teams conferencing platforms.
- Three HDMI video outputs for flexible display configurations.
Ideal For
- Extra-large conference rooms, boardrooms, and ProAV spaces needing multi-camera coverage
- Native Microsoft Teams Rooms standardization at scale
- Rooms requiring synchronized speaker tracking across a larger space than a single-camera kit covers
- Deployments needing BYOD flexibility alongside a native Teams install
- Complex room layouts scaling beyond a two-camera setup, using AVHub's expansion capability
Yealink MVC S90-C5U-004 Native Microsoft Teams Rooms Multi-Camera System for Extra-Large Rooms (1106799)
The MVC S90-C5U-004 is a complete Native Microsoft Teams Rooms on Windows system built for extra-large rooms and ProAV spaces, centered on two UVC86 4K Ultra HD PTZ cameras with 12x optical zoom. An AVHub multi-camera processor manages the feeds, supporting up to 9 simultaneous cameras and driving Multi-Camera IntelliFocus for dynamic framing and seamless transitions between speakers, eliminating the awkward mechanical movements of a single camera.
The kit pairs the cameras with the MCore 4 mini-PC (Intel Ultra5 125H, 16 GB DDR5, 256 GB SSD), preloaded with Windows 11 IoT Enterprise and the Microsoft Teams Rooms app, and the MTouch Plus 11.6-inch touch console for meeting management. The RoomSensor automatically wakes the system on occupancy, and the included MVC-BYOD-Extender lets a connected laptop use the room's cameras and microphones for non-Teams platforms. Before ordering, confirm the room's layout supports placement of both UVC86 cameras, and plan whether the space needs the full 3-camera S98 configuration instead if it's larger still.
Key Specifications
- Manufacturer model: MVC S90-C5U-004 (SKU 1106799)
- System type: Native Microsoft Teams Rooms on Windows, extra-large room / ProAV multi-camera kit
- Cameras: 2x UVC86, 4K Ultra HD, 12x optical zoom, Speaker Tracking, Presenter Tracking
- Camera scalability: up to 9 simultaneous cameras supported via AVHub
- Compute (MCore 4): Intel Ultra5 125H, 16 GB DDR5, 256 GB SSD, 3x HDMI video outputs, Windows 11 IoT Enterprise x64 preloaded with license, Teams Rooms app, Yealink RoomConnect
- Control: MTouch Plus 11.6-inch touchscreen
- Occupancy: RoomSensor, Bluetooth-connected, automatic wake
- Multi-camera processing: AVHub, Multi-Camera IntelliFocus, dynamic framing and speaker transitions
- BYOD: MVC-BYOD-Extender, USB adapter for non-Teams platforms
What's Included
- 2x UVC86 dual-eye intelligent cameras, each with power adapter and cables
- MCore 4 mini-PC, power adapter, and cables
- MTouch Plus touch panel
- AVHub multi-camera processor, power adapter, and cables
- MVC-BYOD-Extender USB-BYOD adapter
- RoomSensor
Certifications and Compatibility
- Native Microsoft Teams Rooms on Windows: certified system, with the MCore 4 running Windows 11 IoT Enterprise and the Teams Rooms app preloaded.
- BYOD platforms: the MVC-BYOD-Extender provides USB connectivity for other conferencing platforms.
- Multi-camera scaling: the AVHub supports up to 9 simultaneous cameras, beyond the 2 UVC86 units included, for rooms that need to scale further.
- Related kit: the MVC S98-C5U-004 is the larger, 3-camera configuration for even more extensive ProAV rooms; confirm the correct SKU for your room size.
- Compatibility is limited to Yealink-published MVC/AVHub components. Confirm current compatibility against Yealink's Teams Rooms accessory documentation for your specific firmware.
Design Considerations
- Confirm the room layout and seating support placement of both UVC86 cameras for effective coverage.
- Plan the AVHub's network and cabling for the two-camera configuration, with room to scale toward the 9-camera maximum if the space grows.
- A Microsoft Teams Rooms license is required for native operation and is separate from the hardware.
- If the room is larger still, compare against the 3-camera MVC S98-C5U-004 configuration.
- For multi-room and multi-site programs, standardize on this kit configuration for every extra-large room to keep camera counts and AVHub configuration consistent.
Licensing, Warranty & Support
The MVC S90-C5U-004 is a Native Microsoft Teams Rooms on Windows system, and a Microsoft Teams Rooms license is required for operation and is not included with the hardware. The MCore 4 ships with Windows 11 IoT Enterprise and its license preloaded. The system is covered by Yealink's standard limited hardware warranty, with terms available from Yealink or an authorized reseller at the time of purchase. Firmware, configuration, and remote management are available through Yealink RoomConnect.
VideoConferenceGear.com Assistance
We can help confirm the MVC S90-C5U-004 is the right fit for your extra-large room, and plan placement for the two UVC86 cameras across the space. We can advise on AVHub cabling and network design, help decide between this kit and the larger 3-camera MVC S98-C5U-004, confirm Microsoft Teams Rooms licensing, and plan BYOD-Extender use for other platforms. For multi-room and multi-site programs we can help standardize this kit across every extra-large room.
Common Questions
How many cameras does this system include?
Two UVC86 cameras, and the AVHub processor supports up to 9 simultaneous cameras for larger or more complex layouts.
Is this Teams Rooms or Zoom Rooms?
Microsoft Teams Rooms on Windows. A Zoom Rooms version (ZVC S90-C5U-004) is a separate kit.
How does this differ from the MVC S98?
The MVC S98-C5U-004 is the larger configuration with three SmartVision 80 cameras rather than two UVC86 cameras. Confirm which size fits your room.
Can it be used with other conferencing platforms?
Yes, through the included MVC-BYOD-Extender, which provides USB connectivity for platforms beyond Teams.
Is a Teams Rooms license included?
No. A Microsoft Teams Rooms license is required for operation and is separate from the hardware.
How many displays can it drive?
Three HDMI video outputs are available on the MCore 4 for flexible display configurations.
