Highlights
- A 10.1-inch capacitive 10-point touchscreen provides an intuitive interface for room scheduling and availability.
- Green or red LED availability lighting lets users quickly identify whether a room is available.
- PoE connectivity carries power over the network, simplifying installation where a PoE-enabled network is available.
- Included multi-surface, corner, and mullion mounting options support glass, drywall, and other room-entrance installations.
- Logitech Sync Remote Management, Microsoft Teams Admin Center, and Zoom Device Management support centralized device administration.
- AES-128 full-disk encryption and device-attestation features support managed enterprise deployments.
Ideal For
- Conference rooms and boardrooms
- Huddle spaces and phone booths
- Room entrances and shared meeting areas
- Corporate offices with multiple reservable rooms
- Multi-location room-scheduling deployments
Resources
Logitech Tap Scheduler 10.1" PoE Room Scheduling Panel with Multi-Surface Mount – Graphite
The Logitech Tap Scheduler is a purpose-built room scheduling panel that gives employees a clear way to view room availability and manage bookings at the room entrance.
Its 10.1-inch capacitive touchscreen, green or red availability lighting, and graphite finish make it a practical choice for organized room-booking deployments without adding a camera, microphone, speaker, or room-compute function.
Logitech Tap Scheduler, the scheduling panel for meeting rooms
Platform Compatibility
- This verifies Microsoft Teams Panels certification, not Microsoft Teams Rooms certification.
Key Specifications
- Display: 10.1-inch diagonal IPS LCD panel with LED backlighting
- Resolution: 1280 x 800
- Touch: Capacitive 10-point multi-touch
- Brightness: 400 nits; contrast ratio: 1000:1
- Viewing angle: 85 degrees up/down/left/right
- Availability indicator: Green or red LED lighting
- Network connectivity: 10/100 Mbps Ethernet; Wi-Fi 802.11a/b/g/n/ac/ax
- Power: Power over Ethernet, IEEE 802.3af Type 1, Class 3 device
- Mounting interface: 100 mm x 100 mm VESA FDMI
- Device dimensions: 6.5 H x 9.69 W x 1.12 D inches (165 x 246.2 x 28.5 mm)
- Surface-mounted dimensions: 6.5 H x 9.69 W x 1.24 D inches (165 x 246.2 x 31.4 mm)
- Mullion-mounted dimensions: 6.5 H x 11.52 W x 1.75 D inches (165 x 292.6 x 44.5 mm)
- Device weight: 700 g (24.7 oz)
- Operating temperature: 0 to 40°C; storage temperature: -40 to 70°C
- Humidity: 10–95%
- Bluetooth 5.0 is inactive and reserved for future use
- Security: AES-128 full-disk encryption, symmetric-key and PKI data encryption, device attestation, and Arm TrustZone key protection
What's Included
- Logitech Tap Scheduler
- Multi-surface mount for glass or drywall
- Corner mount accessory
- Mullion mount
- Mounting hardware
- Documentation
Compatibility
- Meeting and collaboration platforms: Certified Microsoft Teams Panels hardware for Logitech TAP Scheduler model VR0028; this is Teams Panels certification, not Microsoft Teams Rooms system certification.
- Meeting and collaboration platforms: Supported as a Zoom Rooms Scheduling Display and listed among certified Zoom Room scheduler platforms.
- Room-booking and calendar services: Scheduling operation depends on the selected room-booking platform and its calendar integration. Zoom scheduling displays use calendar integration with Google or Exchange.
- Device management: Supports Logitech Sync Remote Management, Microsoft Teams Admin Center, and Zoom Device Management.
- Network and power requirements: Requires a PoE-enabled network meeting IEEE 802.3af Type 1, Class 3 requirements, or a separate PoE injector and Ethernet cable.
- Required supporting equipment: A PoE injector and Ethernet cable are required when the network does not provide PoE; neither is included.
- AV and room-system scope: This is a standalone scheduling panel, not a conference camera, microphone, speaker, video bar, or room-compute device.
Licensing, Warranty & Support
The hardware includes Logitech Sync Basic for Rooms at no additional cost. Sync Basic includes device management, monitoring, updates, a standard two-year limited hardware warranty, and business-hours help desk support. Logitech Sync Essential for Rooms and Sync Select for Rooms are optional paid services listed at $199 per year per room and $399 per year per room, respectively; Essential adds advanced management and room-booking features, while Select adds enhanced support and product coverage benefits. The room-booking platform, calendar integration, and any required platform licensing are separate considerations and must be selected for the intended deployment. A PoE-enabled network or separate PoE injector and Ethernet cable is required for operation, and those items are not included. An optional extended warranty adds one year to the standard warranty; availability for the specific order should be confirmed.
VideoConferenceGear.com Assistance
We can help validate that Tap Scheduler is the right fit for your room entrances and shared spaces, confirm Microsoft Teams Panels or Zoom Rooms Scheduling Display requirements, and identify the needed calendar integration, PoE equipment, mounting approach, and management licensing. We can also coordinate room-system planning, nationwide multi-location deployment, installation, and ongoing support.
Common Questions
Is the PoE injector or Ethernet cable included?
No. Tap Scheduler requires a PoE-enabled network or a separate PoE injector and Ethernet cable, and those items are not included with the panel.
Can Tap Scheduler be used with Microsoft Teams?
Yes. It is certified as Microsoft Teams Panels hardware for Logitech TAP Scheduler model VR0028. That certification applies to Teams Panels, not to a complete Microsoft Teams Rooms system.
Can Tap Scheduler be used with Zoom Rooms?
Yes. It is supported as a Zoom Rooms Scheduling Display and is listed among certified Zoom Room scheduler platforms. The scheduling deployment also depends on the selected calendar integration.
Does Tap Scheduler include room-booking software or a calendar subscription?
No room-booking platform or calendar subscription is included as part of the hardware package. The required platform, calendar integration, and any associated licensing depend on the selected deployment; Logitech Sync Basic is included for device management.
What mounting options are included?
The package includes a multi-surface mount for glass or drywall, a corner mount accessory, a mullion mount, and mounting hardware. Surface-mounted and mullion-mounted dimensions differ, so the installation location should be planned around the selected mount.
